| Model |
Flow（ Nm³/min）
|
Inlet pressure（ MPa）
|
Discharg pressure（MPa）
|
Type/No. of stage
|
Lubrication |
Cooling type
|
Drive（ kW）
|
Size（ mm）
|
Weight（ kg）
|
| VF-1.5/(17-24)-80-C | 25-35 | 1.7-2.4 | 8 | V/2 | Oil lubricated | Air-cooled |
CUMMINS NT855
|
5500×2500×2500 | 6500 |
| VF-1.5/(17-24)-150-C | 25-35 | 1.7-2.4 | 15 | V/3 | Oil lubricated | Air-cooled | CUMMINS NT855 | 5500×2500×2500 | 6500 |
| VF-2.2/(17-24)-150-C | 35-52 | 1.7-2.4 | 15 | V/3 | Oil lubricated | Air-cooled | CUMMINS NT855 | 5500×2500×2500 | 6800 |
| VF-3/(17-24)-80-C | 54-72 | 1.7-2.4 | 8 | V/2 | Oil lubricated | Air-cooled | CUMMINS NT855 | 5500×2500×2500 | 6800 |
| VF-0.95/34.5-80-C | 30.5 | 3.45 | 8 | V/1 | Oil lubricated | Air-cooled | CUMMINS NT855 | 5500×2500×2500 | 6500 |
| VF-0.95/34.5-150-C | 30.5 | 3.45 | 15 | V/2 | Oil lubricated | Air-cooled | CUMMINS NT855 | 5500×2500×2500 | 6500 |
| VF-1.9/34.5-80-C | 61 | 3.45 | 8 | V/1 | Oil lubricated | Air-cooled | CUMMINS NT855 | 5500×2500×2500 | 6500 |
| VF-1.9/34.5-150-C | 61 | 3.45 | 15 | V/2 | Oil lubricated | Air-cooled | CUMMINS NT855 | 5500×2500×2500 | 6800 |
| VF-1.5/(17-24)-80 | 25-35 | 1.7-2.4 | 8 | V/2 | Oil lubricated | Air-cooled | 132kW | 3800×2500×2500 | 5500 |
| VF-1.5/(17-24)-150 | 25-35 | 1.7-2.4 | 15 | V/3 | Oil lubricated | Air-cooled | 185kW | 3800×2500×2500 | 5500 |
| VF-2.2/(17-24)-150 | 39-52 | 1.7-2.4 | 15 | V/3 | Oil lubricated | Air-cooled | 280kW | 3800×2500×2500 | 5800 |
| VF-3/(17-24)-80 | 54-72 | 1.7-2.4 | 8 | V/2 | Oil lubricated | Air-cooled | 280kW | 3800×2500×2500 | 5800 |
| VF-0.95/34.5-80 | 30.5 | 3.45 | 8 | V/1 | Oil lubricated | Air-cooled | 90kW | 3800×2500×2500 | 5500 |
| VF-0.95/34.5-150 | 30.5 | 3.45 | 15 | V/2 | Oil lubricated | Air-cooled | 160kW | 3800×2500×2500 | 5500 |
| VF-1.9/34.5-80 | 61 | 3.45 | 8 | V/1 | Oil lubricated | Air-cooled | 185kW | 3800×2500×2500 | 5500 |
| VF-1.9/34.5-150 | 61 | 3.45 | 15 | V/2 | Oil lubricated | Air-cooled | 315kW | 3800×2500×2500 | 5850 |
